Lingkong LK3U‑24‑6AD‑2DA PLC Controller – 24 I/O, Analog, RS485

by

Intro Summary
The LK3U‑24‑6AD‑2DA is a cost-effective Mitsubishi‑compatible PLC: 24 I/O, analog channels, pulse support—perfect for industrial automation.

Product Overview
The LK3U‑24‑6AD‑2DA is an industrial-grade programmable controller from Lingkong, offering 12 digital inputs, 12 digital outputs, plus 6 analog inputs and 2 analog outputs . Available in relay (MR) or transistor (MT) output versions, it supports high-speed pulse I/O, RS485/RS232 communication, and an optional real-time clock. Compact and reliable, it integrates with GX Works/MX, supports HMI/text-screen, and is compatible with Mitsubishi FX3U series. Ideal for machine control, weighing, data logging, and automation tasks.

How to Use

  1. Mount on DIN rail and power with 24 V DC.
  2. Wire digital I/O, analog I/O, and communication ports per label.
  3. Connect RS232/485 or HMI panel if needed.
  4. Use GX Developer or GX Works to program logic, configure analog scaling, and set high-speed pulse parameters.
  5. Deploy and test I/O functionality.
    Tips: match MR/MT version to your output type. Include proper earthing. Use RS485 for networked PLCs.

Additional helpful content:
• LE3U 24MR FX3U 6AD 2DA high‑speed PLC demo
• Overview of LK3U FX3U series and GX Works programming

Frequently Asked Questions (FAQ)

  1. What does “6AD‐2DA” mean? – 6 analog inputs, 2 analog outputs.
  2. MR vs MT? – MR = relay outputs, MT = transistor outputs.
  3. Supports pulse I/O? – Yes, high-speed pulse input/output included.
  4. Can program with GX Works2? – Yes, fully compatible .
  5. Communication interfaces? – RS485, RS232 standard; RTC optional.
  6. Weight channels? – Supports weighing functions on analog input.
  7. Power requirements? – 24 V DC with max 3 A output on each.
  8. Mounting? – DIN‑rail ready.
  9. Operating temperature? – Typical industrial 0–55 °C (check datasheet).
  10. Warranty? – Often includes 1‑year supplier warranty.

User Review Summary
While reviews on LK3U‑24‑6AD‑2DA are limited, general feedback for LE3U/Fx compatible boards highlights:
👍 Pros: Compact, reliable analog support, stable for industrial use.
👎 Cons: Limited English documentation; analog calibration may require extra effort.

Comparison with Competing Products
• Lingkong LK3U‑48MR/10AD‑2DA: doubles I/O count (48 I/O) at ~€400—better for larger setups.
• BAISULI 80MR/10AD‑2DA Ethernet version: adds Ethernet and CAN for ~US$443, good for networked systems.
• Amazon FX3U‑14MT board: similar analog spec at ~US$40; fewer I/O but cheaper for small projects.

Technical Specifications

  • Digital I/O: 12 DI, 12 DO
  • Analog I/O: 6 channels (0‑10V/0‑20 mA), 2 AO (0‑10V)
  • High‑speed I/O: 2 pulse inputs, 2 pulse outputs
  • Comm: RS232 ×1, RS485 ×2, optional RTC
  • Memory: ~32,000 steps
  • Power: 24 V DC; DO current ≤3 A
  • Mounting: 117 × 108.6 × 65 mm, DIN‑rail
  • Housing: Plastic industrial enclosure

Brand Info
Lingkong (Hunan Hualai Tech) produces cost‑effective, FX3U‑compatible PLCs. Known for stable hardware, analog integration, and automation‑focused products .
